XD3-16R


Product description

1. 8 NPN inputs, 8 relay outputs (R) or transistor outputs (T) or relay & transistor mixed output (RT)
2. AC220V (E) or DC24V (C) power supply
3. CPU can extend ten expansion modules and three BD boards
4. Support RTC, power-off retentive
5. Support basic logic control and data operation
6. The processing speed is 10 times of XC series PLC
7. Support high speed count, pulse output, external interruption, C language function block, free switch for I/O points, free protocol communication and MODBUS communication.

General Specifications
Items
Specifications
Isolation voltage
Above DC 500V 2MΩ
Anti-noise
Noise voltage 1000Vp-p  1us pulse per 1minute
Atmosphere
No corrosive, flammable gas
Ambient temperature
0°C~60°C
Ambient humidity
5%~95% (No condensation)
COM1
RS-232, to connect upper computer, HMI for program or debug.
COM2
RS-232/RS-485, to connect intelligent instruments or inverters.
Installation
Use M3screws or DIN to fix
Grounding
The third type grounding (do not grounding with strong power system)

Functional Specifications
Items
Specifications
Program execution mode
Loop scan mode
Program mode
Instructions and ladder
Processing speed
0.05us
Power off retentive
FlashROM and Li-battery
Users’ program capacity
256KB
I/O points

Total I/O
16
32
60
Input
8 X0~X7
18 X0~X21
36 X0~X43
Output
8 Y0~Y7
14 Y0~Y15
24 Y0~Y27
Internal Coils(X)
X0~X2027(1048)
Internal Coils(Y)
Y0~Y1037(1048)
Internal Coils(M, HM)
11008
M0~M7999[HM0~HM959]
For Special Use   SM0~SM2047

Procedure (S)
1153
S0~S1023[HS0~HS128]
Timer (T)
points
640
T0~T575 [HT0~HT95]
Spec.
100mS timer: set time 0.1~3276.7sec.
10mS timer: set time 0.01~327.67sec.
1mS timer: set time 0.001~32.767sec.
Counter (C)
points
672
C0~C575[HC0~HC95]
Spec.
16 bits counter: set value K0~32,767
32 bits counter: set value -2147483648~+2147483647
Data Register(D)
11048words
D0~D7999[HD0~HD999]
For Special Use  SD0~SD2047

FlashROM Register (FD)
8144 words
FD0~FD6143
For Special Use   SFD0~SFD1999

High Speed Dispose Ability
High speed counter, pulse output, external interruption
Password Protection
6 bits ASCII
Self-diagnose Function
Power on self-check, monitor timer, grammar check


Dimension (Unit: mm)

 Product appearance and size chart


Dimension :unit (mm) chart


XD3-16Re
